AUDIO DYNAMICS 4x 2308D2 AND 1,500 WATT AMP PACKAGE
$1,099.00 USD
This is the perfect sub set up for under the back seat of a pick up or a hatch back this setup will not disappoint. 4x 2308d2 with 1500 watt Audio Dynamics amplifier.
sub specs-
2308 sub
- 150W – 400W optimal power range
- 2″ voice coil diameter
- Designed for use in small vented enclosures.
- Engineered in the USA.
Fs 47.10 Hz Qms 7.49 Vas 5.47 l Cms 0.090 mm/N Mms 118.50 g Rms 4.72 kg/s Dia 159.99 mm Sd 201.08 cm² Qes 0.54 Re 4.11 Ω Le 1.63 mH Z 4.00 Ω Bl 16.20 Tm Bl²/Re 63.80 N²/W Qts 0.51 no 0.10 % SPL 82.15 dB EBP 85.69 Nominal Diameter 8 in Overall Diameter 8.39 in / 213 mm Mounting Hole Diameter 7.13 in / 181 mm Bolt Hole Circle Diameter Motor Outer Diameter 5.70 in / 145 mm Mounting Depth 4.92 in / 125 mm Required Pole Vent Clearance Driver Displacement 0.048 cu ft / 1.37 l Minimum Sealed Volume N/A Minimum Vented Volume 0.42 cu ft / 12 l net*
Amp spec-
X1.5k
- 1,500 Watt Class D Mono Block
- Upgraded with Larger Package MOS-FETS for Increased Avalanche Current
- Upgraded with Lower ESR Capacitors
- Linkable Master / Slave Configurable
- Dual MOS-FET PWM power supply
- Click-in-Place Crossover Controls
- Subsonic and Low Pass Filters
- Tiffany Style RCA Connectors
- Low or High Level RCA Inputs
- Auto turn on (DC or signal sense)
- Remote Bass Control w/ Clip Indicator
- Damping Factor >150
- 80dB Signal to Noise Ratio
- Reversible Top Plate
- 4 AWG Power Terminals
- Engineered in U.S.A. and Korea
