Description

The 6000 series 18 employs a finely-tuned balance of damping and extensive motor force to achieve very high efficiency, offering exceptional versatility and unmatched performance in a variety of real-world functions.

Dual 1ohm

Fs  35.33 Hz
Qms  7.707
Vas  41.02 liters
Cms  0.025 mm/N
Mms  827.1 g
Rms   23.38 kg/s
Dia  370 mm
Sd  1075 sq cm

Qes  0.658
Re  1.842 ohms
Le  1.929 mH

BL 22.68 Tm

Qts 0.606
no 0.265 %
SPL 86.38 dB
EBP 53.69

Dual 2ohm

Fs  29.78 Hz
Qms  5.314
Vas  69.09 liters
Cms  0.041 mm/N
Mms  691.2 g
Rms  24.53 kg/s
Dia  371 mm
Sd  1080 sq cm

Qes  0.669
Re  3.881 ohms
Le  2.618 mH

BL 27.39 Tm

Qts 0.594
no 0.263 %
SPL 86.35 dB
EBP 44.51

XMax 23.5mm

Nominal Diameter 18in
Overall Diameter 18.11in / 460mm
Mounting Hole Diameter 16.77in / 426mm

Motor Outer Diameter 11.02in / 280mm
Mounting Depth 12.08in / 307mm
Required Pole Vent Clearance
Driver Displacement  cu ft /  l

Minimum Sealed Volume N/A
Vented Volume  2.4 – 6.4cu.ft. Net
