• 3,000 Watt Class D Mono Block
• Upgraded with Larger Package MOS-FETS for Increased Avalanche Current
• Upgraded with Lower ESR Capacitors
• Linkable Master / Slave Configurable
• Dual MOS-FET PWM power supply
• Click-in-Place Crossover Controls
• Subsonic and Low Pass Filters
• Tiffany Style RCA Connectors
• Low or High Level RCA Inputs
• Auto turn on (DC or signal sense)
• Remote Bass Control w/ Clip Indicator
• Damping Factor >150
• 80dB Signal to Noise Ratio
• Reversible Top Plate
• 0 AWG Power Terminals
• Engineered in U.S.A. and Korea

Description
 Continuous Power    1200W x 1 @ 4 ohms
 At 14.4V Supply Voltage    2000W x 1 @ 2 ohms
3000W x 1 @ 1 ohm
 Frequency Response    13Hz – 270Hz
 Input Sensitivity    0.4V to 6V
 Fuse Ratings    125A @ 4 ohms / 200A @ 2 ohms / 300A @ 1 ohm
 Filter Modes    High Pass and Low Pass
 High Pass Filter @ 24dB/Oct    10Hz – 50Hz
     Linkwitz-Riley
 Low Pass Filter @ 24dB/Oct    35Hz – 250Hz
 Linkwitz-Riley
 Detented Filter Potentiometers    41 Click-in-Place Frequencies
 Remote Level Control w/ Clip Indicator    Included
 Pass-Through Output    Yes
 Height    2.88 in / 73 mm
 Width    7.81 in / 198 mm
 Length (Heat Sink)    15.75 in / 400 mm
 Net Weight    12 lb / 5.44 kg
